Chevrolet Blazer S15 (1994-1998) illuminated entry Wiring diagram
This page shows the only wiring diagram for the component.illuminated entry, which is found in the car Chevrolet Blazer S15 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram illuminated entry (1 of 1)
4 DOOR
BATTERY
BLK WIRE
COURTESY SWITCH
CTSY FUSE 2
DOME LAMP
DOOR HANDLE INPUT
ENDGATE JAMB SWITCH
ENDGATE LOCK SWITCH
GAUGES FUSE 4
GRD
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P COMPARTMENT BOX LAMP
I/P DIMMER SWITCH
I/P FUSE BLOCK
ILLUMINATED ENTRY
LAMP CTRL
LEFT DOOR HANDLE SWITCH
LEFT FRONT DOOR JAMB SWITCH
LEFT I/P COURTESY LAMP
LEFT REAR DOOR JAMB SWITCH (4 DOOR)
LEFT VANITY MIRROR LAMP
ORG/ WIRE
PARK LPS FUSE 3
PNK IGN WIRE
PNK WIRE
REAR DOME LAMP, SWITCH
REMOTE KEYLESS ENTRY MODULE (NEAR PARK BRAKE)
RIGHT DOOR HANDLE SWITCH
RIGHT FRONT DOOR JAMB SWITCH
RIGHT I/P COURTESY LAMP
RIGHT REAR DOOR JAMB SWITCH
RIGHT VANITY MIRROR LAMP
TRANSFER CASE CONTROL MODULE (CENTER OF I/P)
UNDER- HOOD LAMP
WHT WIRE
Go to component -> Courtesy lamps circuit -> ILLUMINATED ENTRY
