Chevrolet Blazer S15 (1994-1998) hot with light switch in park or head Wiring diagram
This page shows the only wiring diagram for the component.hot with light switch in park or head, which is found in the car Chevrolet Blazer S15 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot with light switch in park or head (1 of 1)
1995 VFTC
BLK WIRE
GAUGES FUSE 4
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
HOT WITH LIGHT SWITCH IN PARK OR HEAD
I/P FUSE BLOCK
ILLUM FUSE 21
ILLUMINATION LAMP
ON/OFF SWITCH
ORG/ WIRE
PNK WIRE
PPL
REAR DEFOGGER GRID
REAR WINDOW DEFOGGER SWITCH
RR DEFOG FUSE 8
SOLID STATE TIMING CIRCUIT
Go to component -> Defogger circuit -> HOT WITH LIGHT SWITCH IN PARK OR HEAD
