Chevrolet Blazer III facelift (2022-2024) transmission input shaft Wiring diagram
This page shows the only wiring diagram for the component.transmission input shaft, which is found in the car Chevrolet Blazer III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission input shaft (1 of 1)
2.0L TURBO
3.6L
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE
ENGINE CONTROLS SYSTEM
GRN/YEL WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
IGNITION MODE SW MODE CTRL
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY TRANSFORMER (UNDER CENTER OF INSTRUMENT PANEL)
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RUN/CRANK IGN 1 VOLT
STARTER ENABLE RLY CTRL
STARTER PINION SOL RLY CTRL
TRANSMISSION CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
TRANSMISSION INPUT SHAFT
TRANSMISSION RANGE SENSOR
VIO/BLK WIRE
VIO/GRY WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Starting circuit (2 of 2) -> TRANSMISSION INPUT SHAFT
