Chevrolet Blazer III facelift (2022-2024) lr seat cushion temp sensor sig Wiring diagram

BATT POSITIVE VOLT BCM LIN BUS 2 BLK WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/YEL WIRE GRY WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES LEFT REAR CUSHION SEAT HEATING ELEMENT LEFT REAR SEAT HEATING SWITCH LR CUSHION THERMISTOR FEEDBACK SIG LR HEATED SEAT CUSHION ELEMENT CTRL LR HEATED SEAT CUSHION ELEMENT LOW REF BATT POSITIVE VOLT LR HTD SEAT SW SIG LR SEAT CUSHION TEMP SENSOR SIG NCA WIRE REAR BODY FUSE BLOCK REAR SEAT HEATING CONTROL MODULE RED/WHT WIRE RIGHT REAR CUSHION SEAT HEATING ELEMENT RIGHT REAR SEAT HEATING SWITCH RR CUSHION THERMISTOR FEEDBACK SIG RR HEATED SEAT CUSHION ELEMENT CTRL RR HEATED SEAT ELEMENT LO REF RR HTD SEAT HIGH IND CTRL LR HTD SEAT HIGH IND CTRL RR HTD SEAT SW SIG RR SEAT CUSHION TEMP SENSOR SIG WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/WHT WIRE
