Chevrolet Blazer III facelift (2022-2024) ambient lt sens sig Wiring diagram
This page shows the only wiring diagram for the component.ambient lt sens sig, which is found in the car Chevrolet Blazer III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient lt sens sig (1 of 1)
AIR COND COMPRESSOR SOL VALVE CTRL
AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF INSTRUMENT PANEL)
AMBIENT LT SENS SIG
BATT POS VOLT
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLOWER MOTOR
BLOWER SPD
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BLWR MTR SPD CTRL
BODY CONTROL MODULE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
FEEDBACK SIG
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HVAC CONTROL MODULE (BEHIND HVAC CONTROLS)
HVAC CTRL MOD LIN BUS 1
INSIDE AIR TEMP SENS SIG
INSTRUMENT PANEL FUSE BLOCK
LEFT OF BATTERY)
LO SPD GMLAN SERIAL DATA
LOGIC
NCA WIRE
REAR DEFOG RLY CTRL
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RUN/CRANK IGN 1 VOLT AIR COND COMPRESSOR SOL VALVE CTRL
SOLAR SENS LO REF
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WINDSHIELD TEMPERATURE, INSIDE MOISTURE SENSOR
YEL WIRE
YEL/VIO WIRE
Go to component -> 2.0l vin 4, automatic a/c circuit (1 of 6) -> AMBIENT LT SENS SIG
