Car Wiring Diagrams for 3.6l vin s, shift interlock circuit for Chevrolet Blazer III (2018-2023)

2.0L TURBO 2.5L 3.6L AUTOMATIC TRANSMISSION ASSEMBLY BATTERY POSITIVE VOLT BRK APPLY SENS LOW REF BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE BRAKE PEDAL POSITION SENSOR BRK APPLY SENS CTRL BRK APPLY SENS SIG BRK POS SENS LOW REF BRK POS SENS SIG COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE GRN/YEL WIRE GRY/YEL WIRE HI SPD GMLAN SERIAL DATA (-) (1) HI SPEED GMLAN SER DATA (-) 1 HI SPEED GMLAN SERIAL DATA (-) 1 HOT AT ALL TIMES IGNITION MODE SW MODE CTRL IGNITION MODE SW MODE CTRL BACKUP IMS MODE SW LO REF INSTRUMENT PANEL FUSE BLOCK J193 (2.0L TURBO) J194 (2.0L TURBO) KEY CAPTURE/COLUMN LOCK SHIFT POS SIG NCA WIRE PARK LOCK SOL CTRL PARK POSITION SWITCH RED/BRN WIRE TRANS POS SENS REF TRANSMISSION CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION SHIFT LEVER TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLU WIRE
