Chevrolet Blazer III (2018-2023) turbo charger bypass solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.turbo charger bypass solenoid valve, which is found in the car Chevrolet Blazer III (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turbo charger bypass solenoid valve (1 of 1)
2.0L TURBO
2.5L
2.5L 2.0L TURBO
2.5L 3.6L
3.6L
A/C COMPRESSOR CLUTCH RELAY
ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR
AUXILIARY COOLANT PUMP RELAY
BLU WIRE
ENGINE CONTROL MODULE
ENGINE CONTROLS IGNITION RELAY
ENGINE COOLANT FLOW CONTROL VALVE
ENGINE COOLANT FLOW CONTROL VALVE BLOCK
ENGINE OIL PRESSURE CONTROL SOLENOID VALVE
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
EXHAUST CAMSHAFT PROFILE ACTUATOR 2
EXHAUST CAMSHAFT PROFILE ACTUATOR 3
FROM IGNITION MAIN RELAY (DIAGRAM 2 OF 9)
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INTAKE CAMSHAFT POSITION ACTUATOR PARK LOCK SOLENOID VALVE BANK 1
INTAKE CAMSHAFT POSITION ACTUATOR PARK LOCK SOLENOID VALVE BANK 2
INTAKE CAMSHAFT PROFILE ACTUATOR 1
INTAKE CAMSHAFT PROFILE ACTUATOR 2
INTAKE CAMSHAFT PROFILE ACTUATOR 3
INTAKE CAMSHAFT PROFILE ACTUATOR 4
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
TURBO CHARGER BYPASS SOLENOID VALVE
VALVE LIFTER OIL SOLENOID VALVE BANK 1
VALVE LIFTER OIL SOLENOID VALVE BANK 2
VIO WIRE
VIO/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (9 of 9) -> TURBO CHARGER BYPASS SOLENOID VALVE
