Chevrolet Blazer III (2018-2023) trans hi side drv 2 sig Wiring diagram
This page shows the only wiring diagram for the component.trans hi side drv 2 sig, which is found in the car Chevrolet Blazer III (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans hi side drv 2 sig (1 of 1)
2.5L
3.6L
3.6L 2.5L
ACCESSORY WAKEUP SERIAL DATA
ACCUMULATOR SOL
AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
BATT POSITIVE VOLT
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH A CTRL
CLUTCH B CTRL
CLUTCH C CTRL
CLUTCH D CTRL
CLUTCH E CTRL TCC/CLUTCH SOL CTRL TCC ON/OFF SOLENOID A CTRL
COMPUTER DATA LINES SYSTEM
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN MODE SW MODE CTRL
IN SPD SIG
LEFT OF BATTERY)
OUT SPD SIG
RED/GRN WIRE
RUN/CRANK IGNITION 1 VOLT
SIG GND
TRANS CLUTCH F CTRL
TRANS CLUTCH G CTRL
TRANS CLUTCH H CTRL
TRANS HI SIDE DRV 1 SIG
TRANS HI SIDE DRV 2 SIG
TRANS INTERMEDIATE SPD SIG
TRANS OIL LVL SENS SIG 1 SHIFT SOLENOID VALVE CTRL
TRANS OIL TEMP SENS LO REF
TRANS OIL TEMP SENS SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INPUT/INTERMEDIATE SHAFT SPEED SENSOR
TRANSMISSION INTERMEDIATE SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> A/t circuit (1 of 3) -> TRANS HI SIDE DRV 2 SIG
