Chevrolet Blazer III (2018-2023) left rear side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear side impact sensor, which is found in the car Chevrolet Blazer III (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side impact sensor (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BRN/ORG WIRE
DRIVER KNEE AIR BAG
FRONT OVERHEAD CONSOLE ASSEMBLY
GRN WIRE
GRY/ORG WIRE
LEFT FRONT IMPACT SENSOR
LEFT FRONT SIDE IMPACT SENSOR
LEFT REAR SIDE IMPACT SENSOR
LEFT ROOF RAIL AIR BAG
ORG/BLU WIRE
ORG/GRN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PASSENGER AIR BAG OFF IND
PASSENGER AIR BAG ON IND
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT SIDE IMPACT SENSOR
RIGHT REAR SIDE IMPACT SENSOR
SEAT BELT IND
SHORTING BAR
VIO/ORG WIRE
VIO/WHT WIRE
W/ FULL VIDEO DISPLAY
W/O FULL VIDEO DISPLAY
WHT/ORG WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LEFT REAR SIDE IMPACT SENSOR
