Interval wiper/washer circuit for Chevrolet Beretta I (1987-1996)
Interval wiper/washer circuit
BLK WIRE
BRN WIRE
COVER ASSEMBLY
DELAY INPUT
DK BLU WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (VEHICLE SPEED SENSOR)
FUSE 10
FUSE BLOCK
GRN WIRE
GRY WIRE
HI LO OFF PULSE
HI MIST LO
HI MIST LO OFF DELAY
HOT IN ACCY OR RUN
MECHANICAL ARM
MIST
MIST HI LO OFF DELAY
OFF DELAY
PARK SWITCH
PPL
RED WIRE
SOLID STATE TIMER DELAY OUTPUT
VEHICLE SPEED INPUT
WASHER MOTOR
WASHER SWITCH
WIPER MOTOR ASSEMBLY
WIPER SWITCH
WIPER/ WASHER SWITCH
YEL WIRE
