Charging circuit for Chevrolet Beretta I (1987-1996)

Charging circuit

Beretta Chevrolet I (1987-1996): Charging circuit

Get access

BASE CLUSTER ONLY BATTERY BLK WIRE BRN WIRE CHARGE IND FUSE 9 FUSE 4 FUSE BLOCK FUSIBLE LINK FUSIBLE LINK (16 GA-RUST) FUSIBLE LINK (20 GA-RUST) GENERATOR (UPPER RIGHT FRONT OF ENGINE) TURN ON INPUT TURN ON INPUT GROUND DISTRIBUTION HOT IN RUN HOT IN RUN, BULB TEST OR START INSTRUMENT CLUSTER PNK WIRE POWER DISTRIBUTION RECTIFIER BRIDGE RED WIRE REGULATOR FIELD (SOLID STATE) (ROTOR) STARTER SOLENOID (LOWER LEFT REAR OF ENGINE) STATOR VOLTAGE SENSING INPUT
