Passive restraint circuit for Chevrolet Beretta I (1987-1996)
Passive restraint circuit
BATTERY
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER
DK GRN WIRE
ENGINE CONTROL MODULE
FASTEN BELTS INDICATOR CONTROL
FUSE 11
FUSE 9
FUSE BLOCK
GROUND
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
IGNITION
INSTRUMENT CLUSTER FASTEN BELTS INDICATOR
LEFT FRONT DOOR HANDLE
LEFT FRONT DOOR OPEN INPUT
LEFT SEAT BELT LAP RETRACTOR RELEASE SOLENOID
LEFT SEAT BELT SHOULDER RETRACTOR RELEASE SOLENOID
LT BLU WIRE
LT GRN/BLK WIRE
MULTI-FUNCTION ALARM MODULE
NCA WIRE
ORG/ WIRE
PNK WIRE
RIGHT FRONT DOOR HANDLE
RIGHT FRONT DOOR OPEN INPUT
RIGHT SEAT BELT LAP RETRACTOR RELEASE SOLENOID
RIGHT SEAT BELT SHOULDER RETRACTOR RELEASE SOLENOID
SEAT BELT INPUT
SEAT BELT SOLENOID CONTROL
SEAT BELT SWITCH
SUPPLEMENTAL RESTRAINT SYSTEM
SWITCH
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT
WHT WIRE
YEL WIRE
