Instrument illumination circuit for Chevrolet Beretta I (1987-1996)
Instrument illumination circuit
1995 VFTC
BLK WIRE
CANADIAN MODELS ONLY
CONSOLE ASHTRAY LIGHT
CONSOLE SHIFT LIGHT
CONVIENCE CENTER (LEFT SIDE OF I/P, ABOVE FUSE BLOCK)
COUPE ONLY
DAYTIME RUNNING LIGHTS (DRL) MODULE (RIGHT SIDE OF I/P, ABOVE GLOVE BOX)
DISPLAY DIM SIGNAL
DK GRN WIRE
EXTERIOR LIGHTS SYSTEM (REAR LIGHTS)
FUSE 13
FUSE BLOCK (BEHIND LEFT SIDE OF I/P)
GRY WIRE
HEADLIGHT SWITCH
HEATER, A/C CONTROL ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LIGHT SWITCH
LIGHT SWITCH LIGHT
MULTI-FUNCTION ALARM MDULE
OFF HEAD PARK
PWM MODULE
RADIO
REAR DEFOGGER CONTROL, WIPER/WASHER SWITCH
SEDAN ONLY
W/REAR DEFOGGER
