Chevrolet Beretta I (1987-1996) from turn/ hazard switch wiring diagram
This page shows the only wiring diagram for the component.from turn/ hazard switch, which is found in the car Chevrolet Beretta I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
from turn/ hazard switch wiring diagram (1 of 1)
1995 VFTC
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COUPE
DK BLU WIRE
FROM LIGHT SWITCH
FROM TURN/ HAZARD SWITCH
LEFT FRONT MARKER LIGHT (W/O FOG LIGHTS)
LEFT FRONT PARK/TURN LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE LIGHT
LEFT REAR MARKER LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT TAIL/ STOP/TURN LIGHTS
LICENSE LIGHT
LT BLU WIRE
PARK
PARK TURN
RIGHT FRONT MARKER LIGHT (W/O FOG LIGHTS)
RIGHT FRONT PARK/TURN LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAIL/ STOP/TURN LIGHTS
SEDAN
STOP TAIL TURN
STOP TURN
STOP- TURN TAIL
STOP- TURN TAIL STOP- TURN TAIL
TAIL
TAIL STOP TURN
TURN
TURN PARK
Go to component -> Exterior light circuit (2 of 2) -> FROM TURN/ HAZARD SWITCH
