Chevrolet Beretta I (1987-1996) fog lts in-line Wiring diagram
This page shows the only wiring diagram for the component.fog lts in-line, which is found in the car Chevrolet Beretta I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog lts in-line (1 of 1)
B/H CONN
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
FOG LT RELAY (UPPER LEFT SIDE OF I/P)
FOG LT SW
FOG LTS IN-LINE
FOG LTS IND
HEAD
HEADLT DIMMER
HEADLT SW
HI BEAM HEADLT HI BEAM HEADLT
HI-BEAM IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT FOG LT
LEFT LO COMPOSITE BEAM HEADLT HEADLT ASSEMBLY
LIGHT SW
LO BEAM HEADLT
LO HI SW
LT GRN WIRE
OFF
ORG/ WIRE
PARK
PPL
RIGHT COMPOSITE HEADLT ASSEMBLY
RIGHT FOG LT
TAN WIRE
YEL WIRE
Go to component -> Fog lamps circuit, without drl -> FOG LTS IN-LINE
