Chevrolet Beretta I (1987-1996) console window sw wiring diagram
This page shows the only wiring diagram for the component.console window sw, which is found in the car Chevrolet Beretta I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
console window sw wiring diagram (1 of 1)
4 DOOR
A/C/HEATER CONSOLE CONTROL WINDOW SW ASSEMBLY
ALTERNATOR
B/H CONN
BLK WIRE
BRAKE LUGGAGE SW COMPT RELEASE SW
BRN WIRE
BRN/BLK WIRE
CB #12
CIG LIGHTER
CONSOLE WINDOW SW
COUPE
CRANKCASE VENT HEATER
DAYTIME RUNNING LTS MODULE
DOOR UNLOCK MODULE
ELECTRONIC ELECTRONIC BRAKE BRAKE CONTROL CONTROL RELAY MODULE
FROM FUS LINK B
FROM FUS LINK D
FROM IGNITION SW
FROM LT SW
FUSE #4 FUSE BLOCK
FUSE 11
FUSE 2
FUSE 6
FUSE 7
FUSE 8
HAZARD FLASHER
HEATED OXYGEN SENSOR
HORN RELAY LEFT RIGHT FUNCTION ALARM FRONT DOOR MODULE LOCK SWITCHES
LEFT FRONT LEFT FRONT MARKER LT PARK/TURN LT
LEFT FRONT SIDE MARKER LT
LEFT LICENSE LT
LEFT REAR LICENSE SIDE MARKER LT LT
LEFT REAR SIDE MARKER LT
LEFT REAR WINDOW SW
LEFT TAIL/STOP, LEFT REAR TURN LTS MARKER LT
LEFT TAIL/STOP/ TURN LTS
MULTI-
MULTI-FUNCTION ALARM MODULE
ONLY
ORG/ WIRE
RADIO DAYTIME RUNNING LTS MODULE
RED WIRE
RIGHT FRONT RIGHT FRONT PARK/TURN MARKER LT LT
RIGHT FRONT SIDE MARKER LT
RIGHT REAR SIDE MARKER LT
RIGHT REAR WINDOW SW
RIGHT RIGHT REAR RIGHT TAIL/STOP, LICENSE LT SIDE MARKER TURN LTS LT
RIGHT TAIL/STOP, RIGHT REAR TURN LTS MARKER LT
SEDAN
TEMP VALVE MOTOR
TO FUSE #17
TO LIGHT SW
Go to component -> Power distribution circuit (2 of 3) -> CONSOLE WINDOW SW
