Supplemental restraints circuit, without restraint suppression for Chevrolet Aveo I facelift (2006-2012)
Supplemental restraints circuit, without restraint suppression (1 of 2)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CLUSTER
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT
FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW CENTER CONSOLE)
LEFT LOW REF RH LOW REF LEFT SIG RH SIG
LF SEAT BELT SW
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/WHT WIRE
OBD
ORG/ WIRE
ORG/WHT WIRE
PNK WIRE
RED/WHT WIRE
RESTRAINT SYSTEM
SDM
SWITCH (DRIVER SEAT BELT BUCKLE)
VOL+ ING 1 VOL PNK WIRE
W/ DRIVER SEAT INFLATABLE
W/O DRIVER SEAT INFLATABLE
WHT WIRE
Supplemental restraints circuit, without restraint suppression (2 of 2)
5 6 PNK WIRE
AIR BAG IND
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLOCK
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT RETRACTOR
GRY WIRE
GRY/BLK WIRE
IGN
INFLATABLE RESTRAINT I/P MODULE (RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT STEERING WHEEL MODULE (CENTER OF STEERING WHEEL)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (UNDER DRIVER AIR BAG MODULE)
INSTRUMENT CLUSTER PANEL (IPC)
LOGIC
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PASSENGER SEAT BELT RETRACTOR
PNK WIRE
PPL
PRETENSIONER
SEAT BELT IND
SHORTING BAR
TAN/BLK WIRE
WHT WIRE
YEL WIRE
