Car Wiring Diagrams for Starting circuit for Chevrolet Aveo I facelift (2006-2012)

1807 710 323 323 COMPUTER DATA LINES SYSTEM BATTERY BLK WIRE BRN WIRE CHARGING CIRCUIT ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY) FUSE IGN 2/ST PARK/NEUTRAL POSITION (PNP) SWITCH (SIDE OF TRANSAXLE) PPL 10 11 29 26 RED WIRE STARTER B+ MOTOR STARTER RELAY STRT RLY P/N SIG UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) YEL WIRE
