Instrument illumination circuit for Chevrolet Aveo I facelift (2006-2012)

Instrument illumination circuit

Get access

AUTOMATIC TRANSM- ISSION SHIFT PROGRAM SWITCH (4 SPEED TRANS- MISSION) AUTOMATIC TRANSMISSION SHIFT LEVER POSITION BLK GRN/ DK WIRE BLK WIRE BRN/WHT WIRE CIGAR LIGHTER (IF EQUI- PPED) CLOCK DK GRN WIRE DRIVER SEAT HEATED SWITCH (IF EQUIPPED) FUSE HAZARD WARNING SWITCH HEADLAMPS LEVELING MODULE (IF EQUIPPED) HOT AT ALL TIMES HVAC CONTROL MODULE (AUTOMATIC A/C) (CENTER OF DASH) HVAC CONTROL MODULE (MANUAL A/C) (CENTER OF DASH) I/P DIMMER SWITCH (IF EQUIPPED) I/P FUSE BLOCK INDICATOR (4 SPEED TRANS- MISSION) INSTRU- MENT PANEL CLUSTER (IPC) LOGIC LT BLU WIRE PARK HEAD OFF PARK LAMP RELAY PK/LP POWER DISTRIBUTION SYSTEM RADIO SHUNT SWITCH TURN SIGNAL/ MULTI-FUNCTION UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/ I/P DIMMER SWITCH W/O I/P DIMMER SWITCH WHT BRN WIRE WHT GRN/ DK WIRE WHT WIRE
