Backup lamps circuit, hatchback for Chevrolet Aveo I facelift (2006-2012)
Backup lamps circuit, hatchback
B/UP LAMP FUSE
BACKUP SWITCH (TRANS- MISSION ASSEMBLY)
BLK WIRE
BRN WIRE
ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY)
I/P FUSE BLOCK
LEFT BACKUP LAMP
LT GRN WIRE
M/T A/T
PARK/NEUTRAL POSITION (PNP) SWITCH (SIDE OF TRANSAXLE)
RELAY ENERGIZED
RIGHT BACKUP LAMP
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
