Compressor circuit, with auto a/c for Chevrolet Aveo I facelift (2006-2012)
Compressor circuit, with auto a/c
4 41 A/C COMP A/C REQ SIG PPL
45 33 LOW REF 5-VOLT REF 1
A/C COMP
A/C COMPRESSOR CLUTCH (LOWER RIGHT FRONT OF ENGINE)
A/C REFRIGERANT PRESSURE SENSOR (HIGH PRESSURE REFRIGERANT LINE)
A/C RELAY
BLK WIRE
BRN WIRE
ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY)
FUSE
HOT AT AT TIMES
HOT W/ MAIN RELAY ENERGIZED
LT BLU WIRE
ORG/BLK WIRE
PPL
PPL/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
