Chevrolet Aveo I facelift (2006-2012) w/o driver inflatable restraint system w/ driver inflatable restraint system Wiring diagram
This page shows the only wiring diagram for the component.w/o driver inflatable restraint system w/ driver inflatable restraint system, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o driver inflatable restraint system w/ driver inflatable restraint system (1 of 1)
AUDIO/ RKE
B/UP LAMP
BLK WIRE
BRN/WHT WIRE
CHIME CTRL
CLUSTER
CLUSTER/ROOM LAMP
DOOR AJAR IND B(+)
FOG LP SW SPLY VOLT
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
I/P FUSE BLOCK
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW CENTER CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
KEY IN IGN SW SIG
LEFT FRONT DOOR JAMB SWITCH (LEFT FRONT "B" PILLAR)
LEFT SEAT BELT SWITCH (DRIVER SEAT BELT BUCKLE)
LF SEAT BELT SW
LOGIC
LT GRN WIRE
OFF ON
ORG/ WIRE
PPL
PPL/WHT WIRE
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (UNDER LEFT SIDE OF DASH)
SEAT BELT IND IGN 1 VOLT
W/ PASSIVE KEY LESS ENTRY W/ ACOUSTICAL
W/O DRIVER INFLATABLE RESTRAINT SYSTEM W/ DRIVER INFLATABLE RESTRAINT SYSTEM
WHT WIRE
Go to component -> Chime circuit -> W/O DRIVER INFLATABLE RESTRAINT SYSTEM W/ DRIVER INFLATABLE RESTRAINT SYSTEM
