Chevrolet Aveo I facelift (2006-2012) w/ high w/o high level stop lamp level stop lamp Wiring diagram
This page shows the only wiring diagram for the component.w/ high w/o high level stop lamp level stop lamp, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ high w/o high level stop lamp level stop lamp (1 of 1)
BLK WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DATA LINK CONNECTOR (DLC)
DRIVER SEAT BELT SWITCH
EQUIPPED)
FUEL PUMP
I/P DIMMER SWITCH
I/P FUSE BLOCK
IGN 1 RELAY
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT RIGHT LICENSE LICENSE LAMP LAMP
LEFT RIGHT TAIL TAIL LAMP LAMP
LT GRN WIRE
NOTCH- 8 1 BACK HATCH- BACK
NOTCHBACK HATCHBACK
OUTSIDE REARVIEW MIRROR SWITCH
OVERHEAD CONSOLE COURTESY/ READING LAMPS
PASSENGER OUTSIDE REARVIEW MIRROR
REAR COMPARTMENT LID AJAR SWITCH
REAR WINDOW DEFOGGER GRID
SHIELD DRAIN WIRE 1
SUNROOF CONTROL MODULE
THEFT DETERRENT MODULE (TDM)
TURN SIGNAL/ HAZARD FLASHER MODULE
TURN SIGNAL/ MULTIFUNCTION SWITCH
W/ ABZ W/O ABZ
W/ ELEC SLIDING GLASS SUN ROOF
W/ HIGH W/O HIGH LEVEL STOP LAMP LEVEL STOP LAMP
W/ RR SPOILER W/O REAR SPOILER
W/O HIGH W/ HIGH LEVEL STOP LEVEL STOP LAMP LAMP
WHT WIRE
Go to component -> Ground distribution circuit (2 of 2) -> W/ HIGH W/O HIGH LEVEL STOP LAMP LEVEL STOP LAMP
