Chevrolet Aveo I facelift (2006-2012) vol sol ctrl Wiring diagram
This page shows the only wiring diagram for the component.vol sol ctrl, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vol sol ctrl (1 of 1)
BLK WIRE
BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH)
BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH)
BLOWER MOTOR SWITCH
BRN WIRE
FUSE
HOT AT AT TIMES
HOT IN ACC
HVAC CONTROL MODULE (CENTER OF DASH)
IGN 2 RELAY
IGN 3 VOLT
LT BLU WIRE
OFF
ORG/ WIRE
RED/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VOL SOL CTRL
YEL WIRE
Go to component -> Heater circuit -> VOL SOL CTRL
