Chevrolet Aveo I facelift (2006-2012) neutral safety sw sig hi spd gm lan serial data Wiring diagram
This page shows the only wiring diagram for the component.neutral safety sw sig hi spd gm lan serial data, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram neutral safety sw sig hi spd gm lan serial data (1 of 1)
26 10 NEUTRAL START SIG HIGH SPEED
323 1807 1807 710 710 PPL PPL GMLAN SERIAL DATA LOW SPEED GMLAN SERIAL DATA
A/T SHIFT LOCK CONTROL SOLENOID
AUTOMATIC TRANSMISSION SHIFT LEVER
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CTRL RELEASE SIG
ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY)
FUSE
HOT IN RUN OR START
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
IGNITION KEY CYLINDER SOLENOID LOCK INHIBIT
IGNITION LOCK CYLINDER CONTROL ACTUATOR
INSTRUMENT PANEL CLUSTER (IPC)
LO SPD GMLAN SERIAL DATA
LOGIC
LOGIC CLUSTER
LT GRN WIRE
NEUTRAL SAFETY SW SIG HI SPD GM LAN SERIAL DATA
ORG/BLK WIRE
P/N SIGNAL
PARK POSITION SWITCH
PARK/NEUTRAL POSITION (PNP) SWITCH (SIDE OF TRANSAXLE)
PNK WIRE
PPL
PPL COMPUTER DATA LINES SYSTEM
STOP LAMP SWITCH (BRAKE PEDAL ASSEMBLY)
TAN WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> NEUTRAL SAFETY SW SIG HI SPD GM LAN SERIAL DATA
