Chevrolet Aveo I facelift (2006-2012) mtr retract ctrl Wiring diagram
This page shows the only wiring diagram for the component.mtr retract ctrl, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mtr retract ctrl (1 of 1)
6 3 1 8 HATCHBACK NOTCHBACK
AMP PRESENT SIG
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER
DEFOGGER SYSTEM
DOWN
FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HATCHBACK NOTCHBACK 6 3 1 8 1 1 2 2 5 6
HOT AT ALL TIMES
HOT IN ON
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
IGN 3 VOLT
LEFT
LEFT OUTSIDE REARVIEW MIRROR
LEFT RIGHT
LOGIC OUTSIDE REARVIEW MIRROR FOLDING MODULE (IF EQUIPPED)
LT BLU WIRE
LT LT
MIRROR/SUNROOF
MTR EXTEND CTRL
MTR RETRACT CTRL
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DRIVER
RED WIRE
RED/WHT WIRE
RIGHT
RIGHT OUTSIDE REARVIEW MIRROR
UP DOWN
UP/ DOWN LEFT/ RIGHT
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> MTR RETRACT CTRL
