Chevrolet Aveo I facelift (2006-2012) left low ref rh low ref left sig rh sig Wiring diagram
This page shows the only wiring diagram for the component.left low ref rh low ref left sig rh sig, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left low ref rh low ref left sig rh sig (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CLUSTER
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT
FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW CENTER CONSOLE)
LEFT LOW REF RH LOW REF LEFT SIG RH SIG
LF SEAT BELT SW
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/WHT WIRE
OBD
ORG/ WIRE
ORG/WHT WIRE
PNK WIRE
RED/WHT WIRE
RESTRAINT SYSTEM
SDM
SWITCH (DRIVER SEAT BELT BUCKLE)
VOL+ ING 1 VOL PNK WIRE
W/ DRIVER SEAT INFLATABLE
W/O DRIVER SEAT INFLATABLE
WHT WIRE
Go to component -> Supplemental restraints circuit, without restraint suppression (1 of 2) -> LEFT LOW REF RH LOW REF LEFT SIG RH SIG
