Chevrolet Aveo I facelift (2006-2012) dr dr rly lk un lk lk un lk rly rly ctrl coil Wiring diagrams
This page contains all the electrical diagrams for the component. dr dr rly lk un lk lk un lk rly rly ctrl coil, in which he is found in the car Chevrolet Aveo I facelift (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dr dr rly lk un lk lk un lk rly rly ctrl coil (1 of 2)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR DR RLY LK UN LK LK UN LK RLY RLY CTRL COIL
DR LK DR
GRN WIRE
GRY WIRE
HATCHBACK
HAZARD FUSE
HOOD AJAR SWITCH (LEFT SIDE OF RADIATOR SUPPORT)
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
LIFTGATE AJAR SWITCH (CENTER OF LIFTGATE)
LIFTGATE LOCK ACTUATOR
LOGIC
LT BLU WIRE
LT GRN WIRE
NOTCHBACK
PASSENGER DOOR LATCH (REAR OF PASSENGER DOOR)
PNK/BLK WIRE
PPL
RED WIRE
RED/WHT WIRE
RIGHT REAR DOOR LATCH (REAR OF RIGHT REAR DOOR)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Anti-theft circuit (2 of 2) -> DR DR RLY LK UN LK LK UN LK RLY RLY CTRL COIL
Wiring diagram dr dr rly lk un lk lk un lk rly rly ctrl coil (2 of 2)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR DR RLY LK UN LK LK UN LK RLY RLY CTRL COIL
DR LK DR
GRN WIRE
GRY WIRE
HATCHBACK
HAZARD FUSE
HOOD AJAR SWITCH (LEFT SIDE OF RADIATOR SUPPORT)
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
LIFTGATE AJAR SWITCH (CENTER OF LIFTGATE)
LIFTGATE LOCK ACTUATOR
LOGIC
LT BLU WIRE
LT GRN WIRE
NOTCHBACK
PASSENGER DOOR LATCH (REAR OF PASSENGER DOOR)
PNK/BLK WIRE
PPL
RED WIRE
RED/WHT WIRE
RIGHT REAR DOOR LATCH (REAR OF RIGHT REAR DOOR)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Power door locks circuit (2 of 2) -> DR DR RLY LK UN LK LK UN LK RLY RLY CTRL COIL
