Chevrolet Aveo I facelift (2006-2012) close ctrl open ctrl low reference soft stop sig sw range sig Wiring diagram
This page shows the only wiring diagram for the component.close ctrl open ctrl low reference soft stop sig sw range sig, which is found in the car Chevrolet Aveo I facelift (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close ctrl open ctrl low reference soft stop sig sw range sig (1 of 1)
1 2 3 4 5 6 SUNROOF SW CLOSE SIG
BATT VOLT GROUND
BLK WIRE
BRN WIRE
CLOSE CTRL OPEN CTRL LOW REFERENCE SOFT STOP SIG SW RANGE SIG
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (LEFT SIDE OF DASH, IN DOOR OPENING)
LIMIT SWITCH
LOGIC SUNROOF CONTROL MODULE (ROOF PANEL)
MIRROR/ SUNROOF FUSE
OPEN CLOSED
OVERHEAD CONSOLE COURTESY/READING LAMPS
RED/WHT WIRE
SUNROOF FUSE
SUNROOF MOTOR (FRONT OF ROOF)
SUNROOF SW OPEN SIG
SUNROOF SWITCH
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> CLOSE CTRL OPEN CTRL LOW REFERENCE SOFT STOP SIG SW RANGE SIG
