Chevrolet Aveo I facelift (2006-2012) (below engine control module) Wiring diagrams
This page contains all the electrical diagrams for the component. (below engine control module), in which he is found in the car Chevrolet Aveo I facelift (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(below engine control module) wiring diagram (1 of 2)
A/T
ACC/RAP RELAY
AUTOMATIC TRANSMISSION SHIFT LEVER CLOCK
AUTOMATIC TRANSMISSION SHIFT PROGRAM SWITCH
BACKUP LAMP SWITCH
BATTERY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
CIGAR LIGHTER
ENGINE CONTROL MODULE (ECM)
ENGINE COOLING FAN
F/PUMP RELAY
IGN 2 RELAY
IGNITION CONTROL MODULE (ICM)
IGNITION CONTROL MODULE (ICM) SHIELD
INPUT SHAFT SPEED SENSOR (ISS) SHIELD
INSTRUMENT PANEL CLUSTER (IPC)
LEFT HEADLAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT RIGHT HORN HORN
LT GRN WIRE
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
PARK/NEUTRAL POSITION (PNP) SWITCH
RADIO
RIGHT HEADLAMP
RIGHT PARK/TURN SIGNAL LAMP
RIGHT TAIL/STOP LAMP
STARTER RELAY
TRANSMISSION CONTROL MODULE (TCM)
VEHICLE SPEED SENSOR (VSS)
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 2) -> (BELOW ENGINE CONTROL MODULE)
(below engine control module) wiring diagram (2 of 2)
1807 710 323 323 COMPUTER DATA LINES SYSTEM
BATTERY
BLK WIRE
BRN WIRE
CHARGING CIRCUIT
ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY)
FUSE
IGN 2/ST
PARK/NEUTRAL POSITION (PNP) SWITCH (SIDE OF TRANSAXLE)
PPL 10 11 29 26
RED WIRE
STARTER B+ MOTOR
STARTER RELAY
STRT RLY P/N SIG
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Starting circuit -> (BELOW ENGINE CONTROL MODULE)
