Wiper/washer circuit for Chevrolet Aveo I (2003-2008)
Wiper/washer circuit
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FRONT WINDSHIELD WASHER FLUID PUMP (LEFT SIDE OF ENGINE COMPT)
GRY WIRE
HATCHBACK
HI OFF
HOT IN RUN OR START
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LO INT
LT GRN WIRE
OFF
PPL
REAR WASHER PUMP SWITCH
REAR WIPER SWITCH
RED WIRE
WHT WIRE
WINDSHIELD WIPER MOTOR (IN COWL AT BASE OF WINDSHIELD)
WINDSHIELD WIPER/ WASHER SWITCH
WINDSHIELD/ WASHER PUMP SWITCH
WIPER RELAY
WIPER/ WASHER FUSE 17
