Instrument illumination circuit, with dimmer for Chevrolet Aveo I (2003-2008)
Instrument illumination circuit, with dimmer
BLK WIRE
BRN WIRE
DEFOGGER SWITCH
DIMMER CONTROLS
DK BLU WIRE
GRN WIRE
HAZARD SWITCH
HEAD
HEADLAMP LEVELING SWITCH
HEADLAMP SWITCH PARK OFF
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HVAC CONTROL SWITCH
I/P CLUSTER
I/P DIMMER SWITCH
ILLUM LAMP
ILLUM RH
ILLUMINATION RELAY
LAMP CONTROL MODULE (BEHIND DRIVER SIDE KNEE BOLSTER)
LT BLU WIRE
PPL
PPL/ (IN I/P HARNESS, NEAR RADIO)
RADIO
REAR FOG LAMP SWITCH
SHIFT INDICATOR LAMP
SHIFT PROGRAM SWITCH
SPLICE PACK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ LAMP CONTROL MODULE
W/O LAMP CONTROL MODULE
WHT WIRE
