Courtesy lamps circuit for Chevrolet Aveo I (2003-2008)
Courtesy lamps circuit
BLK WIRE
BRN WIRE
COURTESY/ READING LAMP
DK GRN WIRE
DOOR LOCKS, INSTRUMENT CLUSTER SYSTEMS
HOT AT ALL TIMES
LEFT FRONT DOOR JAMB SWITCH
NOTCHBACK HATCHBACK
OFF
ON DOOR
ORG/ WIRE
REAR COMPARTMENT LAMP
REAR COMPARTMENT LID SWITCH (ON REAR COMPT LID LOCK CYLINDER)
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (UNDER FLOOR CONSOLE)
RIGHT LEFT FRONT REAR DOOR DOOR JAMB JAMB SWITCH SWITCH
RIGHT REAR DOOR JAMB SWITCH
ROOM LAMP
SUNROOF SWITCH/ COURTESY/ READING LAMP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ SUNROOF
W/O SUNROOF
WHT WIRE
