Cooling fan circuit for Chevrolet Aveo I (2003-2008)

Cooling fan circuit

Get access

50 34 36 LOW SPD CTRL HI SPD CTRL MAIN RELAY BLK WIRE BRN WIRE COOLING COOLING FAN (BEHIND RADIATOR) COOLING FAN HI RELAY COOLING FAN LOW RELAY COOLING FAN RESISTOR (BEHIND RIGHT SIDE OF RADIATOR) ECT SENS ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES IRC 1 LOW REF LT GRN WIRE MAIN RELAY PPL PPL (IN FRONT HARNESS) WHT WIRE
