Chevrolet Aveo I (2003-2008) ppl shift lock ctrl lock cyl ctrl ground brake sw park sw Wiring diagram
This page shows the only wiring diagram for the component.ppl shift lock ctrl lock cyl ctrl ground brake sw park sw, which is found in the car Chevrolet Aveo I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl shift lock ctrl lock cyl ctrl ground brake sw park sw (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID
ACC VOLT
AUDIO, CLOCK
AUTOMATIC TRANSMISSION SHIFT LEVER PARK POSITION SWITCH
BACKUP LAMP
BLK WIRE
BLK/DK GRN WIRE
BRN WIRE
DK GRN WIRE
DK GRN/RED WIRE
DK GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
HOT IN RUN OR START
I/P FUSE BLOCK
IGNITION LOCK CYLINDER CONTROL ACTUATOR
IGNITION LOCK MODULE (IN PASSENGER COMPARTMENT FUSE BLOCK)
PNK WIRE
PPL
PPL SHIFT LOCK CTRL LOCK CYL CTRL GROUND BRAKE SW PARK SW
RED WIRE
SPLICE PACK
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> PPL SHIFT LOCK CTRL LOCK CYL CTRL GROUND BRAKE SW PARK SW
