Chevrolet Aveo I (2003-2008) lights on sig batt savr sig batt volt ground lt dr ajar sig key in ign sig wiring diagram
This page shows the only wiring diagram for the component.lights on sig batt savr sig batt volt ground lt dr ajar sig key in ign sig, which is found in the car Chevrolet Aveo I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lights on sig batt savr sig batt volt ground lt dr ajar sig key in ign sig wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
BRN/DK BLU WIRE
HATCHBACK
HEAD
HEADLAMP SWITCH
HOT AT ALL TIMES
ILLUM LAMP
ILLUM LH
ILLUM RELAY
ILLUM RH
LAMP CONTROL MODULE (BEHIND DRIVER SIDE KNEE BOLSTER)
LEFT FRONT DOOR JAM SWITCH
LEFT FRONT PARK POSITION LAMP LEFT FRONT TURN SIGNAL LAMP
LEFT SIDE MARKER LAMP LICENSE LAMP
LEFT TAIL LAMP
LIGHTS ON SIG BATT SAVR SIG BATT VOLT GROUND LT DR AJAR SIG KEY IN IGN SIG
LT BLU WIRE
LT GRN WIRE
NOTCHBACK
OFF PARK
ORG/ WIRE
PPL
PPL PPL
RIGHT FRONT PARK POSITION LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT REAR TAIL LAMP
RIGHT SIDE MARKER LAMP
TURN SIGNAL SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> LIGHTS ON SIG BATT SAVR SIG BATT VOLT GROUND LT DR AJAR SIG KEY IN IGN SIG
