Chevrolet Aveo I (2003-2008) 50 34 36 low spd ctrl hi spd ctrl main relay Wiring diagram
This page shows the only wiring diagram for the component.50 34 36 low spd ctrl hi spd ctrl main relay, which is found in the car Chevrolet Aveo I (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 50 34 36 low spd ctrl hi spd ctrl main relay (1 of 1)
50 34 36 LOW SPD CTRL HI SPD CTRL MAIN RELAY
BLK WIRE
BRN WIRE
COOLING
COOLING FAN (BEHIND RADIATOR)
COOLING FAN HI RELAY
COOLING FAN LOW RELAY
COOLING FAN RESISTOR (BEHIND RIGHT SIDE OF RADIATOR)
ECT SENS
ENGINE CONTROL MODULE (ECM) (LEFT FRONT FENDER, NEAR THE BATTERY)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IRC 1
LOW REF
LT GRN WIRE
MAIN RELAY
PPL
PPL (IN FRONT HARNESS)
WHT WIRE
Go to component -> Cooling fan circuit -> 50 34 36 LOW SPD CTRL HI SPD CTRL MAIN RELAY
