Rear view camera circuit, without one piece liftgate for Chevrolet Avalanche II (2006-2013)
Rear view camera circuit, without one piece liftgate
6 7 CAMERA SIG + CAMERA SIG -
7 6 CAMERA SIG - CAMERA SIG +
BACKUP LP CTRL
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BREAKOUT)
CAMERA VID SIG (+)
DK BLU WIRE
DRAIN WIRE
GROUND
GRY WIRE
HOT W/ RUN/ CRNK RELAY ENERGIZED
IGNITION VOLTAGE
LOGIC INSIDE REARVIEW MIRROR (ISRVM)
LT BLU WIRE
MIRROR DISPLAY
MISC-IGN FUSE 43
NCA WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RADIO
REARVIEW CAMERA (MIDDLE OF LIFTGATE)
REVERSE SIGNAL
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/O RADIO
WHT WIRE
