Chevrolet Avalanche II (2006-2013) w/ spo rear vision Wiring diagram
This page shows the only wiring diagram for the component.w/ spo rear vision, which is found in the car Chevrolet Avalanche II (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ spo rear vision (1 of 1)
1 GRD 1 GRD
AUTOMATIC TRANSMISSION (6 SPEED A/T)
AUTOMATIC TRANSMISSION (HYBRID)
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS)
BACKUP CTRL
BACKUP LAMP RLY CTRL
BCK/UP LAMP PCB RELAY
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
GMC CADILLAC W/O ONE PIECE LIFTGATE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE HOLDER (ON POSITIVE BATTERY POST)
INSIDE REARVIEW MIRROR (ISRVM)
LEFT BACKUP LAMP RIGHT BACKUP LAMP
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
LT GRN WIRE
MJR 3 MJR 3
NCA WIRE
POWER DISTRIBUTION SYSTEM
REARVIEW CAMERA (IF EQUIPPED) (MIDDLE OF TAILGATE)
RED WIRE
RED/BLK WIRE
SER DATA BUS -
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEH BCK/UP FUSE 15
W/ LIFTGLASS HYBRID
W/ SPO REAR VISION
W/O SPO REAR VISION
YEL WIRE
Go to component -> Backup lamps circuit -> W/ SPO REAR VISION
