Chevrolet Avalanche II (2006-2013) s/roof fuse 34 wiring diagram
This page shows the only wiring diagram for the component.s/roof fuse 34, which is found in the car Chevrolet Avalanche II (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
s/roof fuse 34 wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 B+ GROUND SW EXPRESS SIG
6 8 4 2 5 3 PNK WIRE
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
CLOSE
DK GRN WIRE
EXPRESS CLOSE
EXPRESS OPEN
HEADLINER)
HOT AT ALL TIMES
IGN VOLT
ILLUMINATION LAMP
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
ORG/ WIRE
ORG/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH)
ROOF BEACON RELAY (W/ MOUNTED ROOF LAMP PROVISIONS) (IN OVERHEAD CONSOLE)
ROOF OPEN SIG VENT CLOSE SIG ROOF CLOSE SIG VENT OPEN SIG PNK WIRE
S/ROOF FUSE 34
SUNROOF MODULE (FRONT OF
SUNROOF MOTOR
SUNROOF SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VENT
YEL WIRE
Go to component -> Sunroof circuit -> S/ROOF FUSE 34
