Chevrolet Avalanche II (2006-2013) right front inflatable restraint side impact module Wiring diagram
This page shows the only wiring diagram for the component.right front inflatable restraint side impact module, which is found in the car Chevrolet Avalanche II (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front inflatable restraint side impact module (1 of 1)
1 1 RH ROOF RAIL MOD HIGH CTRL RH ROOF RAIL MOD LOW CTRL
13-14, 15-16, 17-18, 37-38, 39-40, 53-54)
BLK/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER DRIVER'S SEAT)
LEFT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
MANUAL LIFT GATE W/ LIFT GLASS
MANUAL LIFT GATE W/O LIFT GLASS
NCA WIRE
ORG/ WIRE
PASSENGER INFLATABLE RESTRAINT SEAT POSITION SENSOR
PASSENGER SEAT BELT SWITCH
PIN SHORTING BARS ENGAGED WHEN MODULE CONNECTOR IS DISCONNECTED FROM HARNESS:
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RIGHT FRONT INFLATABLE RESTRAINT ROOF RAIL MODULE (TOP OF RIGHT "C" PILLAR)
RIGHT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE
SHORTING BAR
TAN/BLK WIRE
TAN/ORG WIRE
TAN/WHT WIRE
W/ NON-BUCKET INDIVIDUAL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> RIGHT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE
