Chevrolet Avalanche II (2006-2013) l/gate cntrl wiring diagram
This page shows the only wiring diagram for the component.l/gate cntrl, which is found in the car Chevrolet Avalanche II (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
l/gate cntrl wiring diagram (1 of 1)
11 3 L/GATE SIG L/GLASS SIG
1303 2279 PPL
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
CADILLAC GMC/CHEVROLET
DK GRN/WHT WIRE
GMC, CHEVROLET, CADILLAC EXCEPT
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES I/P FUSE REAR WPR FUSE BLOCK (LEFT END OF DASH)
L/GATE CNTRL
L/GATE SIG
LIFTGATE LATCH ASSEMBLY (CENTER OF LIFTGATE)
LIFTGATE WINDOW LATCH ASSEMBLY
LOGIC REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
POWER LIFTGATE MODULE (LEFT REAR OF CARGO AREA)
PPL
REAR WASH FUSE 23
REAR WASH PCB RELAY
REAR WINDOW WASHER FLUID PUMP (WASHER FLUID RESERVOIR)
RED/WHT WIRE
RELEASE CTRL 2 B+ GROUND AJAR SW SIG RELEASE CTRL SW SIG
RR WPR VOLT
TAN WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/O POWER LIFTGATE W/ POWER LIFTGATE CADILLAC HYBRID
WHT WIRE
Go to component -> Rear wiper/washer circuit -> L/GATE CNTRL
