Chevrolet Avalanche II (2006-2013) fan-1 fuse 57 pwr/ trn relay Wiring diagrams
This page contains all the electrical diagrams for the component. fan-1 fuse 57 pwr/ trn relay, in which he is found in the car Chevrolet Avalanche II (2006-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fan-1 fuse 57 pwr/ trn relay (1 of 2)
BLK WIRE
BRN WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FAN CNTRL RELAY
FAN HI RELAY
FAN LO RELAY
FAN-1 FUSE 57 PWR/ TRN RELAY
FAN-2 FUSE 60
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT AIR TEMPERATURE ACTUATOR (UNDER LEFT SIDE OF HVAC MODULE)
LEFT COOLING FAN (BEHIND RADIATOR)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MODE ACTUATOR (LEFT SIDE OF HVAC MODULE)
ORG/BLK WIRE
PNK WIRE
PPL
RECIRCULATION ACTUATOR (UPPER RIGHT OF HVAC MODULE)
RIGHT AIR TEMPERATURE ACTUATOR (TOP OF HVAC MODULE)
RIGHT COOLING FAN (BEHIND RADIATOR)
TAN WIRE
UNDER- HOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> FAN-1 FUSE 57 PWR/ TRN RELAY
Wiring diagram fan-1 fuse 57 pwr/ trn relay (2 of 2)
BLK WIRE
COIL CTRL
DK BLU/WHT WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF LEFT CYLINDER HEAD)
FAN CNTRL RELAY
FAN HI RELAY
FAN LO RELAY
FAN-1 FUSE 57 PWR/ TRN RELAY
FAN-2 FUSE 60
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FAN (BEHIND RADIATOR)
LOW REF
LT BLU WIRE
RIGHT COOLING FAN (BEHIND RADIATOR)
RLY CTRL
SENS SIG
TAN WIRE
UNDER- HOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Cooling fan circuit -> FAN-1 FUSE 57 PWR/ TRN RELAY
