Chevrolet Avalanche II (2006-2013) comm data Wiring diagram
This page shows the only wiring diagram for the component.comm data, which is found in the car Chevrolet Avalanche II (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram comm data (1 of 1)
ABS-1 FUSE 61
BLK WIRE
BLK/WHT WIRE
BRAKE PRESSURE MODULATOR
BRN WIRE
COMM DATA
COMPUTER DATA LINES SYSTEM
DIMMING CTRL CAN BUS HI
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT REAR FRAME RAIL)
GND GMLAN+ GMLAN+ LF WHEEL SENS CTRL LF WHEEL SENS SIG
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HEAVY DUTY ABS FUSE 59
HOT AT ALL TIMES
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/BLK WIRE
RADIO
RED WIRE
RED/BLK WIRE
SERIAL DATA B+ GMLAN- GMLAN- LOW REF RF WHEEL SENS CTRL
STEERING ANG SENS B CAN BUS LOW
STEERING ANGLE SENSOR (BASE OF STEERING COLUMN)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VALVE (BPMV)
VSS
W/ LUXURY EDITION W/O LUXURY EDITION
YAW RATE, LATERAL ACCELERATION SENSOR (UNDER FRONT PASSENGER'S SEAT)
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti lock brake circuit, without jd9 (1 of 2) -> COMM DATA
