Chevrolet Avalanche II (2006-2013) alc exh sol ctrl damping rly ctl Wiring diagram

5 VOLT REF 5 VOLT REF 5 VOLT REF 5 VOLT REF 5 VOLT REF PPL ALC EXH SOL CTRL DAMPING RLY CTL ALC/COMP FUSE 58 AUTOMATIC LEVEL CONTROL (ALC) AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR AUTOMATIC LEVEL CONTROL (ALC) RELAY (NEAR UNDERHOOD FUSE BLOCK) AUTOMATIC LEVEL CONTROL (ALC) SENSOR BLK WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) COMM COMPRESSOR MOTOR COMPUTER DATA LINES SYSTEM DATA DK BLU/BLK WIRE DK BLU/WHT WIRE DK GRN WIRE ELECTRONIC SUSPENSION CONTROL MODULE (LEFT REAR OF FRAME CHASSIS) ENABLE GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN OR START LEFT FRONT SUSPENSION DAMPER SOLENOID (LEFT FRONT SUSPENSION DAMPER) LEFT REAR SUSPENSION DAMPER SOLENOID (LEFT REAR SUSPENSION DAMPER) LF SUSP POS SENS RF SUSP POS SENS RR SUSP POS SENS LOW REF LOW REF LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT SUSPENSION DAMPER SOLENOID (RIGHT FRONT SUSPENSION DAMPER) RIGHT REAR SUSPENSION DAMPER SOLENOID (RIGHT REAR SUSPENSION DAMPER) SEO/ALC FUSE 54 SOLENOID VALVE TAN WIRE TAN/BLK WIRE TAN/WHT WIRE WHT WIRE
