Rear defogger circuit for Chevrolet Avalanche I (2001-2006)
Rear defogger circuit
AVALANCHE/ ESCALADE EXT
BLK WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES
HOT IN RUN, START
HTR
HVAC CONTROL MODULE (BEHIND CENTER OF DASH)
I/P RELAY BLOCK (LOWER LEFT SIDE OF DASH)
IGN
LEFT CARGO DOOR CONTACT PLATE (BODY)
LEFT CARGO DOOR CONTACT PLATE (DOOR)
LEFT CARGO REAR WINDOW DEFOGGER GRID
LIFTGATE DEFOGGER GRID
LOGIC
LT GRN WIRE
PPL
REAR DEFOG SWITCH
REAR DEFOGGER RELAY
REAR WINDOW DEFOGGER GRID
RELAY CNTRL
RIGHT CARGO DOOR CONTACT PLATE (BODY)
RIGHT CARGO DOOR CONTACT PLATE (DOOR)
RIGHT CARGO REAR WINDOW DEFOGGER GRID
SERIAL DATA
SPLICE PACK
W/CARGO DOORS
W/LIFTGATE
WHT WIRE
WINDOW CONTACTOR
