Anti-lock brakes circuit, with vehicle speed enhancement stability for Chevrolet Avalanche I (2001-2006)

ABS/TCS CLASS 2 SERIAL DATA YAW RATE SENSOR LO REF BLK WIRE BRAKE FUSE BRAKE IN BRN WIRE DEL TORQUE DK BLU WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT REAR FRAME RAIL) HOT AT ALL TIMES HOT IN RUN IGNITION 3 VOLT LATERAL ACCELEROMETER SIG LEFT FRONT WHEEL SPEED SENSOR LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LEFT REAR WHEEL SPEED SENSOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT FRONT OF ENG COMPT) PPL PPL/WHT WIRE PRECHARGE MOTOR LO BATTERY (+) GND PRECHARGE MOTOR HI PRECHARGE PUMP RED WIRE REQ TORQUE REQUEST TORQUE SIGNAL DELIVERED TORQUE SIGNAL RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR STEERING WHEEL POS MARKER PULSE SIG STEERING WHEEL POS SIG B STOPLAMP SWITCH (ON TOP OF BRAKE PEDAL BRACKET) TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) ABS FUSE VEHICLE SPEED SENSOR (VSS) (RIGHT REAR OF TRANSMISSION) VSES MOTOR VSES/ECAS FUSE VSS HIGH VSS LOW VSS OUTPUT WHT WIRE YEL WIRE YEL/BLK WIRE

ABS IND. ANTI-THEFT SYSTEM BATTERY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRAKE FLUID LEVEL SWITCH (ON LEFT SIDE OF BRAKE FLUID RESERVOIR) BRAKE IND BRAKE PRESSURE DIFFERENTIAL SWITCH (BELOW MASTER CYLINDER) BRN WIRE CRUISE FUSE DATA LINK CONNECTOR (DLC) (BELOW STEERING COLUMN) DK BLU WIRE DK GRN WIRE GROUND GRY WIRE HOT IN RUN HOT IN RUN OR START IGN E FUSE INSTRUMENT PANEL CLUSTER LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) LO REF LOGIC LT BLU WIRE LT GRN WIRE PNK WIRE PPL SEO IGN FUSE STEERING WHEEL POS MARKER PULSE SIG STEERING WHEEL POSITION SENS SIG STEERING WHEEL POSITION SIG A STEERING WHEEL POSITION SIG B STEERING WHEEL SPEED/ POSITION SENSOR (NEAR BASE OF STEERING COLUMN) THEFT DETERRENT CONTROL MODULE TRACTION CONTROL SWITCH TRANSFER CASE SHIFT CONTROL MODULE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) WHT WIRE YAW RATE FREQUENCY YAW, LATERAL ACCELERATION SENSOR (UNDER RIGHT FRONT SEAT) YEL WIRE
