Chevrolet Avalanche I (2001-2006) trec fuse Wiring diagrams
This page contains all the electrical diagrams for the component. trec fuse, in which he is found in the car Chevrolet Avalanche I (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trec fuse (1 of 2)
AUX PWR FUSE RR HVAC FUSE
AUXILIARY POWER OUTLET (BIN) AUXILIARY POWER OUTLET (FRONT)
AUXILIARY POWER OUTLET (CONSOLE)
BLK WIRE
BLOWER FUSE
BLOWER MOTOR RESISTOR ASSEMBLY
DEFOG RELAY
EXC SEO
EXCEPT LUXURY
F/PMP RELAY
FROM SUNROOF FUSE (DIAGRAM 1 OF 6)
FUSE
GARAGE DOOR OPENER
HEADLAMP BALLAST (LEFT)
HEADLAMP BALLAST (RIGHT)
HVAC CONTROL ASSEMBLY (REAR AUXILIARY)
HVAC CONTROL MODULE
HVAC/ECAS FUSE
I/P RELAY BLOCK (UNDER LEFT SIDE OF DASH, NEAR KICK PANEL)
INFO FUSE
INSTRUMENT PANEL CLUSTER
IPC/DIC FUSE
LH HID FUSE
LUXURY
ORG/ WIRE
OVERHEAD CONSOLE
PCM B FUSE
POWERTRAIN CONTROL MODULE
REAR SEAT ENTERTAINMENT ASSEMBLY
RED WIRE
RH HID FUSE
RIGHT I/P FUSE BLOCK (LOWER RIGHT SIDE OF DASH)
ROOF BEACON RELAY (UPFITTER OPTION)
ROOF BEACON SWITCH (UPFITTER OPTION)
RR DEFOG FUSE
SEO
STOP LP FUSE
STOPLAMP SWITCH
TO LBEC 1 FUSE (DIAGRAM 3 OF 6)
TRANSFER CASE ENCODER MOTOR
TRANSFER CASE SHIFT CONTROL MODULE
TREC FUSE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY)
VEHICLE COMMUNICATION INTERFACE MODULE
VEHICLE COMMUNICATION INTERFACE MODULE REMOTE PLAYBACK DEVICE (CD PLAYER)
W/ADJUSTABLE PEDALS W/O ADJUSTABLE PEDALS
Go to component -> Power distribution circuit (2 of 6) -> TREC FUSE
