Chevrolet Avalanche I (2001-2006) park lamp relay Wiring diagram
This page shows the only wiring diagram for the component.park lamp relay, which is found in the car Chevrolet Avalanche I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park lamp relay (1 of 1)
BACK-UP LAMPS CIRCUIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK LT
FRT PARK FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HAZARD SWITCH
HEAD PARK ANL/ DRL AUTO
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN AND START
I/P RELAY BLOCK
IGN E FUSE
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT RIGHT
LT BLU WIRE
LT GRN WIRE
PARK LAMP RELAY
PNK WIRE
PRK LMP ON
REAR BODY MARKER LAMP
RED WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
SERIAL DATA PRK LMP RLY
SPLICE PACK
STUD 1 FUSE
STUD 2 FUSE
TAN WIRE
TO TRL PARK FUSE
TRAILER CONNECTOR
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDER- HOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> PARK LAMP RELAY
