Chevrolet Avalanche I (2001-2006) driver cargo lamp assembly Wiring diagram
This page shows the only wiring diagram for the component.driver cargo lamp assembly, which is found in the car Chevrolet Avalanche I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver cargo lamp assembly (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CARGO LAMP SWITCH
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER CARGO LAMP ASSEMBLY
FRONT PASSENGER DOOR COURTESY LIGHT
FRONT PASSENGER DOOR MODULE (FPDM) (IN RIGHT FRONT DOOR)
GRY/BLK WIRE
I/P COMPARTMENT LAMP (2003)
I/P RELAY BLOCK (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
LEFT I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH)
LT BLU WIRE
MINI WEDGE (FRONT PASSENGER DOOR JAMB SWITCH)
ORG/ WIRE
PASSENGER CARGO LAMP ASSEMBLY
RIGHT I/P FUSE BLOCK (LOWER RIGHT SIDE OF DASH)
TAN WIRE
WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> DRIVER CARGO LAMP ASSEMBLY
